Alarm Annunciators
- Product Code: Alarm Annunciators
- Availability: In Stock
Product Description
- Standard models available from 2 to 32 windows
- Choice of 3 window sizes and 6 different window colours
- Optically isolated fault inputs with wide fault input voltage range (12 – 240V AC/DC +/-10%)
- Field selection for NO / NC fault input contacts, grouping of alarms, window size configuration
- Space saving due to lower depth of only 100mm
- Integral push buttons for Test, Acknowledge, Mute and Reset operations
- Four SPDT relay outputs (2 for grouping, 1 for external hooter, 1 for ring back sequence)
- 7 Field selectable operation sequences as per ISA standard
- Integral buzzer for audible alarm output of 90 dB
- Communication interface with RS485 Modbus RTU protocol
- Replaceable LEDs, Fast Scan, Manned / Unmanned, Supervisory Relay & Supply fail annunciation available
Ordering infotmation
| Cat. No. | Description |
|---|---|
| AU1D8S | supply volatge -90 - 270 V AC/DC, no.of window -8,window size-small |
| AU1D6SP | supply volatge -90 - 270 V AC/DC, no.of window -6,window size-small |
| AU2D16S | supply volatge -90 - 270 V AC/DC, no.of window -16,window size-small |
| AU2D14SP | supply volatge -90 - 270 V AC/DC, no.of window -14,window size-small |
| AU3D22SP | supply volatge -90 - 270 V AC/DC, no.of window -22,window size-small |
| AU4D32S | supply volatge -90 - 270 V AC/DC, no.of window -32,window size-small |
| AU4D30SP | supply volatge -90 - 270 V AC/DC, no.of window -30,window size-small |
| AD1D8S | supply volatge -18 - 60 V AC/DC, no.of window -8,window size-small |
| AD1D6SP | supply volatge -18 - 60 V AC/DC, no.of window -6,window size-small |
| AD2D16S | supply volatge -18 - 60 V AC/DC, no.of window -16,window size-small |
| AD2D14SP | supply volatge -18 - 60 V AC/DC, no.of window -14,window size-small |
| AD3D24S | supply volatge -18 - 60 V AC/DC, no.of window -24,window size-small |
| AD3D22SP | supply volatge -18 - 60 V AC/DC, no.of window -22,window size-small |
| AD4D32S | supply volatge -18 - 60 V AC/DC, no.of window -32,window size-small |
| AD4D30SP | supply volatge -18 - 60 V AC/DC, no.of window -30,window size-small |
